Karcher HDS 5/11 UX

Karcher entry model upright washer with reel.


The HDS 5/11 UX is a compact hot water high-pressure cleaner which features a 3-piston axial pump, air-cooled 2-pole electric motor and a 15m hose with integrated hose reel. The machine allows for easy transportation and storage thanks to its low weight, compact upright design and large diameter wheels, and is small enough to be transported in a typical estate car. . With simple OFF-COLD-HOT operation, the 5/11 UX is the perfect machine for light-medium duty cleaning tasks where time is of the essence, also featuring the Easy Force Advanced trigger gun for operator comfort.


Technical data

Current type                                              1 – 230 – 240 – 50 Ph

Flow rate                                                    450 l/h

Operating pressure                                  110 – 110 / 11 – 11 bar/MPa

Max. temperature (feed 12 °C) max.     80 °C

Power rating                                              2.2 kW

Consumption fuel oil                                2.4 kg/h

Fuel tank                                                     6.5 litres

Weight                                                         70 KG

Dimensions (L x W x H)                           620 x 620 x 1160 mm



Easy Force Advanced trigger gun

Extended high-pressure trigger gun

High-pressure hose, 15 m

Spray lance, 550 mm

Integral high-pressure hose reel

Anti-twist system (AVS)

Pressure switch control

Additional information

Weight 70 kg
Dimensions 62 × 62 × 116 cm
